1994 Mustang

Section 04-01: Suspension and Wheel Hubs, Front

1994 Mustang Workshop Manual

DESCRIPTION AND OPERATION

The front suspension:

Is a modified McPherson strut design.
Contains a front shock absorber (18124) with front coil spring (5310) mounted between front suspension lower arm (3078) and spring socket in No.2 crossmember (5025) .
Front shock absorbers are non-serviceable and must be replaced as a unit.
Ball joint and front suspension lower arm are not serviced separately and must be replaced as an assembly.
