Section 18-01: Wiring and Circuit Protection | 1993 Mustang Workshop Manual |
| Item | Part Number | Description |
|---|---|---|
| 1 | 12A648 | Engine Coolant Sensor |
| 2 | 9D475 | EGR Valve Positioner |
| 3 | 9B989 | Throttle Position Sensor |
| 4 | 9F715 | Idle Air Control |
| 5 | 12A690 | Wiring Harness Assy |
| 6 | 12A581 | Wiring Harness Assy |
| 7 | 14A163 | Clip (2 Req'd) |
| 8 | — | Existing Stud |
| 9A | 9278 | Oil Pressure Switch Assy |
| 10 | 10884 | Engine Coolant Sender Assy |
| 11 | 6C624 | Low Oil Level Sensor |
| 12 | 12697 | Intake Air Temperature Sensor |
| 13 | 12A297 | Distributor Ignition |
| 14 | 9D930 | Engine Wiring Harness Assy |
| 15 | 12A699 | Knock Sensor |
| A | Tighten to 10.8-24.4 Nm (8-18 Lb-Ft) |
