Section 03-01B: Engine, 5.0L HO and 5.0L Cobra | 1993 Mustang Workshop Manual |
| Description | Nm | Lb-Ft | Lb-In |
|---|---|---|---|
| Air Pump Arm To Water Pump Stud Nut | 16-24 | 12-18 | |
| Throttle Body Attaching Nut | 16-24 | 12-18 | |
| Camshaft Sprocket Gear to Camshaft Bolt | 54-61 | 40-45 | |
| Camshaft Thrust Plate To Cylinder Block Bolt | 12-16 | 9-12 | |
| Connecting Rod — Nut | 26-32 | 19-24 | |
| Cylinder Front Cover Bolt | 16-24 | 12-18 | |
| Cylinder Head Bolt | 9 | 9 | |
| Damper To Crankshaft Bolt | 95-122 | 70-90 | |
| Distributor Hold Down Bolt | 24-35 | 18-26 | |
| EGR Valve To Spacer Intake Manifold 16 | 16-24 | 12-18 | |
| Exhaust Manifold To Cylinder Head Bolt | 32-43 | 26-32 | |
| Fan To Water Pump Hub — Bolt | 20-30 | 15-22 | |
| Flywheel To Crankshaft Bolt | 102-115 | 75-85 | |
| Intake Manifold To Cylinder Head Bolt | 15 | 15 | |
| Main Bearing Cap — Bolt | 81-95 | 60-70 | |
| Oil Filter Insert To Cylinder Block Adapter Bolt | 27-41 | 20-30 | |
| Oil Filter To Cylinder Block 12 | |||
| Oil Inlet Tube To Oil Pump Bolt | 16-24 | 12-18 | |
| Oil Pan Drain Plug | 20-34 | 15-25 | |
| Oil Pan To Cylinder Block — Bolt | 9-14 | 84-124 (Lb-In) | |
| Oil Pump To Cylinder Block — Bolt | 30-43 | 22-32 | |
| Oil Inlet Tube To Main Bearing Cap — Nut | 30-43 | 22-32 | |
| Pulley To Damper Bolt | 47-68 | 35-50 | |
| Rocker Arm Fulcrum Bolt To Cylinder Head | 24-34 | 18-25 | |
| Spark Plug To Cylinder Head | 9-20 | 7-15 | |
| Generator And Secondary Air Injection 3/8 | 30-43 | 22-32 | |
| Pump Bracket To Cylinder Head 3/8 | 30-43 | 22-32 | |
| Pump Bracket To Cylinder Head 7/16 | 54-75 | 40-55 | |
| Secondary Air Injection Pump Pivot Bolt | 47-68 | 35-50 | |
| Secondary Air Injection Pump Arm To Pump | 30-43 | 22-32 | |
| Secondary Air Injection Pump Pulley To Pump Hub | 11-15 | 100-130 (Lb-In) | |
| Valve — Rocker Arm Cover Bolt | 16-20 | 12-15 | |
| Vacuum Fitting/Plug To Intake Manifold w/Teflon Tape | 14-20 | 10-15 | |
| Water Outlet Housing Bolt | 16-24 | 12-18 | |
| Water Pump To Cylinder Block Front Cover Bolt | 16-24 | 12-18 | |
| Tappet Guide Plate | 8-12 | 71-106 (Lb-In) |
